VC-4500 Trailed Compost Turner (top of range)
The flagship trailed turner: 4.5 m rotor, 1,800 m³/h, built for professional composting plants.
Top-of-range 4.5 m trailed compost turner. Hydraulic horizontal folding, in-cab panel, 1,000 L irrigation kit. HARDOX 450 + STRENX 700.
Who it's for
Professional composting plants and very large livestock holdings. If your weekly volume exceeds what any VCC model can process, the VC-4500 is the answer.
Concrete benefits
- Up to 1,800 m³/h: the highest throughput in the range.
- 1,000 mm rotor: balanced to turn material from inside out without strain.
- Hydraulic horizontal folding: easy transport (7.5 × 2.4 m in transport position).
- Right wheel drive: real manoeuvrability, not just nominal.
- HARDOX 450 + STRENX 700: built for decades of intensive use.
Full specifications
Taken straight from the factory data sheet. No rounding.
| Drive | Trailed with driven right wheel |
|---|---|
| Minimum tractor | 180 hp with super-creeper gears |
| Rotor width | 4.5 m |
| Transport dimensions | 7.5 m × 2.4 m |
| Tunnel height | 2 m |
| Hood | 4,500 × 2,000 mm |
| Rotor diameter | 1,000 mm |
| Windrow (width × height) | 4.8 m × 2 m |
| Turning capacity | up to 1,800 m³/h |
| Hydraulic pressure | 190 bar, 200 L/min |
| Wear plates | HARDOX 450 steel |
| Tow points | STRENX 700 steel |
| Folding | Hydraulic horizontal, in-cab control |
| Maintenance | Grease every 8 working hours |
| Optional | 1,000 L irrigation kit |
A closer look at the machine
What buyers ask before they decide
What is the minimum tractor I need?
It depends on the model: from 40 hp (VCC-2000) up to 180 hp (VC-4500). The exact figure for this model is in the technical data block above.
How long until I get finished compost?
Between 8 and 12 weeks with proper turning and the correct moisture. We help you dial in the recipe from the first cycle.
Is it road-legal?
The trailed models (VCC and VC-4500) are type-approved for public roads. Mounted models travel attached to the tractor.
How does after-sales support work?
Directly from our factory in Mazaleón (Spain). Spare parts in stock and phone support from the people who built your machine.
